Raptor XR Designed for DJI Phantom 4 Pro

Last Sold  3 sold in last 14 hours

Item Code: G1056TA

Last updated: 08/06/2023

  • Maximize performance
  • Concurrent dual band 2.4 & 5GHz
  • QuickAttach mounting system
  • Adjustable tilt of the range extender
  •  Ask a Question

    Raptor XR Designed for DJI Phantom 4 Pro

    AED 930

    Ask a Question

      Estimated Delivery: Apr 17 – Apr 19
      ... people are viewing this right now
    Compare
    Guaranteed Safe Checkout

    AED 930

    +

    Specification

    DJI Phantom 4 Pro is a model designed for professionals. The basic kit allows for 30 minutes of uninterrupted flight, maximum speed of 72km/h.
    With 4Hawks range extender antenna ability to work at 2 frequencies at the same time, DJI Phantom 4 Pro receives a great boost to its overall performance, by enhancing signal from oblique antenna signals that ignore noise exceptionally well – this in return allows Phantom 4 Pro to maximize its range in noisy areas. What’s more 4Hawks antenna also increases the range of DJI Phantom 4 Pro significantly, so the drone can reach even further than ever before.
    Last but not least, with 4Hawks range extender, the video quality is always glitch free, thanks to a strong, uninterrupted signal.

    Specification

    electrical & mechanical parameters of Raptor renge extender.

    Electrical parameters

    Frequencies
    Port 1:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Port 2:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Gain
    Port 1:   11 dBi  (+/- 1 dBi) & 14 dBi  (+/- 1 dBi)
    Port 2:   11 dBi  (+/- 1 dBi) & 14 dBi  (+/- 1 dBi)
    VSWR

    Port 1:   < 1.50  (max. < 2.00)
    Port 2:   < 1.50  (max. < 2.00)

    Beamwidth
    Port 1:   70°/40° & 40°/25°
    Port 2:   70°/40° & 40°/25°
    Polarization
    Port 1:   Vertical
    Port 2:   Vertical
    Impedance
    Port 1:   50 Ω
    Port 2:   50 Ω

    Mechanical parameters

    Material
    Antenna:   Samsung ABS, polyurethane, aluminum, Stainless steel, Nylon, PTFE PCB
    Mounting:   Stainless steel + paint
    Weight
    ~ 540g (450g Antenna + 90g Mounting)
    Dimensions
    29.2 x 18.2 x 2.1 cm
    11.50 x 7.16 x 0.83 inch
    Connection
    Port 1:   RP-SMA female
    Port 2:   RP-SMA female
    Tilt adjustment
    5 tilt positions, OnClick system
    Mounting type
    On SMA connectors (Permanent)

    Brand

    DJI
