Raptor SR Designed for DJI Inspire 2

Last Sold  1 sold in last 12 hours

Item Code: G1056TA

Last updated:08/06/2023

  • Concurrent dual band 2.4 & 5 GHz
  • Quick Attach mounting system
  • Adjustable tilt of the range extender
  •  Ask a Question

    Raptor SR Designed for DJI Inspire 2

    AED 930

    Ask a Question

      Estimated Delivery: Jun 19 – Jun 21
      ... people are viewing this right now
    Compare
    Guaranteed Safe Checkout

    AED 930

    +

    Specification

    DJI Inspire 2 is one of newer models made for professional users. It is definitely a flagship of professional models currently available on the market. The drone’s body is made from magnesium alloys. Cameras included are easily interchangeable with quality up to 5.2k. The basic kit allows for up to 30 minutes of uninterrupted flight, maximum speed of 90km/h.
    4Hawks antenna significantly increases  the range of Dji Inspire 2, so the drone can reach even further than ever before. Additionally, the strength of the signal is improved, especially in noisy areas.
    Last but not least, with 4Hawks range extender, the video quality is always glitch free, thanks to a strong, uninterrupted signal, that is supported by two frequencies operating at the same time.

    Specification

    electrical & mechanical parameters of Raptor renge extender.

    Electrical parameters

    Frequencies
    Port 1:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Port 2:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Gain
    Port 1:   8 dBi  (+/- 1 dBi) & 10 dBi  (+/- 1 dBi)
    Port 2:   8 dBi  (+/- 1 dBi) & 10 dBi  (+/- 1 dBi)
    VSWR
    Port 1:   < 1.50  (max. < 2.15)
    Port 2:   < 1.50  (max. < 2.15)
    Beamwidth
    Port 1:   90°/65° & 55°/55°
    Port 2:   90°/65° & 55°/55°
    Polarization
    Port 1:   Vertical
    Port 2:   Vertical
    Impedance
    Port 1:   50 Ω
    Port 2:   50 Ω

    Mechanical parameters

    Material
    Antenna:   Samsung ABS, polyurethane, aluminum, Stainless steel, Nylon, PTFE PCB
    Mounting:   Stainless steel + paint
    Weight
    ~ 200g (110g Antenna + 90g Mounting)
    Dimensions
    16.1 x 9.1 x 1.7 cm
    6.34 x 3.60 x 0.67 inch
    Connection
    Port 1:   RP-SMA female
    Port 2:   RP-SMA female
    Tilt adjustment
    3 tilt positions, OnClick system
    Mounting type
    On SMA connectors (Permanent)

    Brand

    DJI
