Raptor SR Designed for DJI Matrice series

Last Sold  2 sold in last 8 hours

Item Code: G1056TA

Last updated: 08/06/2023

  • QuickAttach mounting system
  • Adjustable tilt of the range extender
  • Dedicated pigtails
  • No drilling required
  •  Ask a Question

    Raptor SR Designed for DJI Matrice series

    Ask a Question

      Estimated Delivery: Apr 17 – Apr 19
      ... people are viewing this right now
    Compare
    Guaranteed Safe Checkout

    Specification

    DJI Matrice is a model that is best known for its industrial usage with a big payload with long flight time. the drone is equipped with exceptional obstacle and aircraft detection systems. It is also possible to operate the drone with two controllers. The basic kit allows for up to 38 minutes of uninterrupted flight, maximum speed of 65km/h.
    4Hawks antenna for DJI Matrice model is operating in 2.4GHz with 9dBi gain and 5.8Gz with 10 dBi Gain additional antenna installed inside controller working in 5GHz frequency that allows operating the drone with 2 controllers. Entire construction is 100% UV protected to assure longevity of the equipment. Additionally, part of the construction is made of aluminum to make the whole construction as light as possible. Mounting is made of stainless steel for rock solid stability.
    Modifying the controller might require an assistance of a professional.

    Specification

    electrical & mechanical parameters of Raptor renge extender.

    Electrical parameters

    Frequencies
    Port 1:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Port 2:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Gain
    Port 1:   9 dBi  (+/- 1 dBi) & 10 dBi  (+/- 1 dBi)
    Port 2:   9 dBi  (+/- 1 dBi) & 10 dBi  (+/- 1 dBi)
    VSWR
    Port 1:   < 1.50  (max. < 2.30)
    Port 2:   < 1.50  (max. < 2.30)
    Beamwidth
    Port 1:  90°/65° & 55°/55°
    Port 2:  90°/65° & 55°/55°
    Polarization
    Port 1:   Vertical
    Port 2:   Vertical
    Impedance
    Port 1:   50 Ω
    Port 2:   50 Ω

    Mechanical parameters

    Material
    Antenna:   Samsung ABS, polyurethane, aluminum, Stainless steel, Nylon, FR4 PCB
    Mounting:   Stainless steel + paint
    Weight
    ~ 200g (110g Antenna + 90g Mounting)
    Dimensions
    16.1 x 9.1 x 1.7 cm
    6.34 x 3.60 x 0.67 inch
    Connection
    Port 1:   RP-SMA female
    Port 2:   RP-SMA female
    Tilt adjustment
    5 tilt positions, OnClick system
    Mounting type
    QuickAttach

    Brand

    DJI
