SPECIFICATIONS:
|
Model
|
UA40 | UA60 | UA80 | UA100 | UA120 | UA150 | UA200 | UA240 | UA300 |
|
Capacity
(VA/Watts) |
400 / 240 | 600/ 360 | 800 /480 | 1000/ 600 | 1200/ 720 | 1500 / 900 | 2000 / 1200 | 2400/ 1440 | 3000 / 1800 |
|
INPUT
|
|||||||||
|
Nominal Input
Voltage |
110/120Vac or 220/230/240 Vac | ||||||||
|
Operating
Voltage Range |
81-145Vac/162-290 Vac | ||||||||
|
Operating
FrequencyRange |
50/60 Hz (1±10%) | ||||||||
|
OUTPUT
|
|||||||||
|
Output Voltage
range (Batt. Mode) |
Simulated Sinewave at nominal voltage ±10% | ||||||||
|
Frequency Range
(Batt. Mode) |
50 Hz or 60 Hz ± 1 Hz | ||||||||
|
Transfer Time
|
Typical 2-6 ms, 10ms max. | ||||||||
|
BATTERY
|
|||||||||
|
Battery Type
& Number |
12V/4.5Ah x 1 | 12V/7Ah x 1 | 12V/9Ah x 1 | 12V/7Ah x 2 | 12V/7Ah x2 | 12V/9Ah x 2 | 12V/9Ah x 2 | 12V/7Ah x 4 | 12V/9Ah x 4 |
|
Typical Recharge
Time |
6-8 hours ( To 90% capacity) | ||||||||
|
PROTECTION
|
|||||||||
|
Full Protection
|
Overload and overcharge protection | ||||||||
|
INDICATORS
|
|||||||||
|
Indicators
|
AC Mode, Battery Mode, Load Level, Battery Level | AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, Battery Low |
|||||||
|
ALARM
|
|||||||||
|
Battery Mode
|
Sounding every 10 seconds | ||||||||
|
Battery Low
|
Sounding every second | ||||||||
|
Overload
|
Sounding every 0.5 second | ||||||||
|
Battery
Replacement Alarm |
Sounding every 2 seconds | ||||||||
|
Fault
|
Continuously sounding | ||||||||
|
Management
|
|||||||||
|
USB & RS-232
port(Optional) |
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7, Linux, Unix, and MAC | ||||||||
|
Environment
|
|||||||||
|
Operating
Temperature |
0- 40°C | ||||||||
|
Humidity Range
|
0-95 % (Non-condensing) | ||||||||
|
Noise Level
|
<40db (1 meter from surface) | ||||||||
|
PHYSICAL
|
|||||||||
|
Dimension,
W x D x H (mm) |
101×298×142 | 149.3×338×162 | 158×380×198 | 144×432.5×207 | |||||
|
Net Weight (kg)
|
3.55 | 4.25 | 4.9 | 7.8 | 8 | 11.1 | 11.5 | 20 | 23 |
|
STANDARDS
|
|||||||||
|
Safety
|
IEC/EN62040-1;IEC/EN60950-1 | ||||||||
|
EMC
|
IEC/EN62040-2;IEC61000-4-2;IEC61000-4-3;IEC61000-4-4;IEC61000-4-5;IEC61000-4-6;IEC61000-4-8 | ||||||||
