LC3 EZVIZ

Specifications”

Model CS-LC3-A0
Light Parameters
Lamp 1
LED SMD LED
Brightness 700 Lumen (+/-10%)
Color Temperature 3000K
Life-span @Ta 25°C 30000H
LED Luminance Brightness adjustable
Ingress Protection Grade IP65
Camera Parameters
Max. Resolution 4MP (2560 × 1440)
Camera Viewing Angle 157° (Diagonal), 140° (Horizontal), 75° (Vertical)
IR Range Max. 10 m (33 ft)
Ingress Protection Grade IP67
Video Parameters
Compression Standard H.264 / H.265
Frame Rate Max. 30 fps, self-adaptive during network transmission
DNR 3D DNR
WDR Supports
Audio Parameters
Audio Input Built-in Omni-direction microphone
Audio Output Built-in loudspeaker
Audio Quality Noise suppression
Function
Smart Alarm AI-powered human detection
Dual-antennas Supports
Two-way Talk Supports
General Function Anti-flicker, dual-stream, heart beat, password protection, watermark
Network Parameters
Wireless 802.11 b/g/n @2.4 GHz only (2T2R, dual-antenna)
Network Configuration AP pairing
Storage
Local Storage Built-in 32 GB eMMC storage
Cloud Storage EZVIZ Cloud Storage
Colors
Available colors Black
General
Working Temperature -30°C to 50°C (-20°F to 120°F), humidity 95% or less (non-condensing)
Power 110VAC – 240VAC, 50 HZ / 60 HZ
Power Consumption Max. 30 W
Product Dimensions 86 x 280 x 120 mm (3.39 x 11.02 x 4.72 inch)
Package Dimensions 156 x 152 x 320 mm (6.14 x 5.98 x 13 inch)
Net Weight 1038g (36.61 oz)
In the box
In the box ‘- LC3 Smart Security Wall-light Camera
– Drill Template
– Screw Kit
– Quick Start Guide
Certifications:
Certifications: CE / ROHS / REACH / WEEE
