D Link DMC-300MSC 100 Base-TX to 100Base-FX multi-mode Fiber (SC) Media Converter
3 sold in last 18 hoursLast updated: 23-09-2023
Item code: G1235GA
- Part No. DMC-300MSC
Overview:
Media converters convert signals that are transmitted from one type of media to another so that they can be transmitted over a different type of media. This series of media converters converts 10/100/1000 Mbps copper ethernet to a 100/1000 Mbps fibre optic connection connection.This allows you to expand your network by connecting longer distance,cables between devices that are otherwise connected with short distance Ethernet cables, such as Cat.6 twisted-pair cables.
Specifications:
| Number of Ports | 1 x 10/100BASE-TX RJ-45 port |
| 1 x 100BASE-FX SC port | |
| Standards | IEEE 802.3 for 10BASE-T/F |
| IEEE 802.3u for 100BASE-TX/FX | |
| Data Transfer Rate | Ethernet: 10 Mbps/20 Mbps (half-duplex/full-duplex) |
| Fast Ethernet: 100 Mbps/200 Mbps (half-duplex/full-duplex) | |
| Duplex Mode | Half-duplex/full-duplex |
| Media Types | 10BASE-T: 2-pair Cat. 3/4/5/5e, Unshielded Twisted Pair (UTP) (up to 100 m) |
| 10/100BASE-TX: 2-pair Cat. 5/5e, Unshielded Twisted Pair (UTP) (up to 100 m) | |
| 100BASE-FX: Multi-mode fi   e optic cable with SC connector (up to 2 km) | |
| Media Exchange Interface | Auto-MDI/MDIX |
| Transmission Mode | Store-and-forward |
| Forwarding Rate | Full wire-speed forwarding rate |
| Diagnostic LEDs | Power |
| Speed (for twisted pair ports) | |
| Full-duplex/Collision | |
| LINK/ACT (for twisted pair ports) | |
| AC Input | 5 V/1 A external power adapter |
Brand
D-LINK
