D Link DGS-3130-30S 30-Port Lite Layer 3 Stackable Managed Switch

Last Sold  4 sold in last 12 hours

Last updated: 23-09-2023

Item code: G1235GA

  • Part No. DGS-3130-30S
  •  Ask a Question

    D Link DGS-3130-30S 30-Port Lite Layer 3 Stackable Managed Switch

    AED 2,630

    Ask a Question

      Estimated Delivery: Apr 17 – Apr 19
      ... people are viewing this right now
    Compare
    Guaranteed Safe Checkout

    AED 2,630

    +

    Description:

    30-Port Lite Layer 3 Stackable Managed Gigabit Switch
    DGS-3130-30TS

    Lite Layer 3 stackable managed switch for a secure enterprise or metro Ethernet access network.

    • 24 x 10/100/1000BASE-T ports
    • 2 x 10GBASE-T and 4 x 10G SFP+ ports provide all the uplink capacity your network needs
    • Premium L2 and L3 features effortlessly improve network efficiency and reduce unnecessary data transfer
    • High redundancy features to provide professional-grade reliability and a longer product life:
      — Dual power inputs
      — Ethernet Ring Protection Switching with <50ms recovery time
      — 6 kV surge protection protects the device and those connected from unexpected surges
      — 802.1d/w/s Spanning Tree Protocol avoids potentially network crippling loops
    • RIP/RIPng and OSFPv2/v3 dynamically map out your network, aiding data to get to its destination via the fastest route possible.
    • Expand capacity in a flash with physical stacking up to 9 units
    • 80 Gbps per device physical stacking bandwidth
    • The Smart fan self-adjusts accordingly to maintain optimal operating temperatures

    Specifications:

    Switch Capacity 168 Gbps
    Max. Packet Forwarding Rate 125 Mpps
    Store & Forwarding Forwading Yes
    Control Module Redundancy Yes
    Dimension 440(W) x 44(H) x 250(D) mm
    Weight 2.98Kg
    Operation Temperature 0 ~ 50 °C
    Storage Temperature - 40 ~ 70 °C
    Operation Humidity 10% ~ 90% RH
    Storage Humidity 5% ~ 90% RH
    Operating Altitude 2000m
    Maximum Power Consumption 30.76 W
    Standby Power Consumption 23.2W
    Maximum Heat Dissipation 104.65 BTU/h
    MTBF 900,546 hours
    Power Input AC:100 ~ 240 V
    Redundant Power Supply DPS-500A
    CPU Speed 1.25GHz
    DRAM Size 1GB DDR4
    Flash Memory Size 256MB NAND
    Packet Buffer Size 2MB
    FAN Yes
    Comply with RoHS 6 Yes
    Energy Efficiency Ethernet (EEE) Yes
    Power Saving By Link Status Yes
    Power Saving By Cable Length Yes
    Power Saving By LED Shut-Off Yes
    Power Saving By Port Shut-Off Yes
    Power Saving By Port Standby Yes
    Power Saving By System Hibernation Yes
    Maximum PoE Budget 0
    Physical Stacking Yes
    Physical Stacking Bandwidth 80G, with stacking port trunking
    Units Per Physical Stack 9
    D-Link Single IP Management (SIM) Yes
    Units Per SIM Stack 32
    MAC Address Table Size 16,384 (16K)
    Black Hole MAC Address Yes
    802.3x Flow Control Yes
    Head-of-line (HOL) Blocking Prevention Yes
    802.1D Spanning Tree (STP) Yes
    802.1w Rapid Spanning Tree (RSTP) Yes
    802.1s Multiple Spanning Tree (MSTP) Yes
    BPDU Filtering Yes
    Root Restriction Yes
    BPDU Restriction Yes
    G.8032 ERPS Yes
    Multiple ERPS Ring Yes
    802.1AX Link Aggregation Yes
    802.3ad Link Aggregation Yes
    Link Aggregation Group Per Device 32
    Max Port Per Link Aggregation Group 8
    Port Mirroring Yes
    Flow-based (ACL) mirroring Yes
    RSPAN Yes
    Jumbo Frame 9,216 (9K) Bytes
    Loopback Detection (LBD) Yes
    L2 Protocol Tunneling Yes
    IGMP Snooping Yes
    Max IGMP Snooping Groups 1,024
    IGMP Snooping Fast Leave Yes
    IGMP Proxy Reporting Yes
    IGMP Authentication Yes
    MLD Snooping Yes
    MLD Snooping Groups 1,024
    MLD Snooping Fast Leave Yes
    MLD Proxy Reporting Yes
    802.1Q VLAN Yes
    VLAN Groups 4094
    Port-based VLAN Yes
    802.1v Protocol-based VLAN Yes
    MAC-based VLAN Yes
    Voice VLAN Yes
    Auto Surveillance VLAN Yes
    GVRP Yes
    Double VLAN (Q in Q) Yes
    Selective Q in Q Yes
    VLAN Translation Yes
    ISM VLAN (Multicast VLAN) Yes
    Asymmetric VLAN Yes
    Private VLAN Yes
    Super VLAN Yes
    VLAN trunking Yes
    IP Interface Yes
    Max Number of IP Interface 16
    Loopback Interface Yes
    ARP Yes
    ARP Entries 2,048
    Gratuitous ARP Yes
    IPv6 Neighbor Discovery (ND) Yes
    ND Entries 1,024
    UDP Helper Yes
    VRRP Yes
    Routing Table Entry 1,024
    L3 Forwarding Table Entry 4,096
    Equal-Cost Multi-Path Route (ECMP) Yes
    Weighted-Cost Multi-Path Route (WCMP) Yes
    Default Route Yes
    Static Route Yes
    Policy-based Route (PBR) Yes
    Null Route Yes
    Route Preference Setting Yes
    Route Redistribution Yes
    RIPv1 Yes
    RIPv2 Yes
    RIPng Yes
    Limited IP Multicast (IGMP Filtering) Yes
    Number of Queue 8
    Class of Service (CoS) Yes
    Two Rate Three Color Marker (trTCM) Yes
    Single Rate Three Color Marker (srTCM) Yes
    Remark 802.1p priority Yes
    Remark ToS/DSCP Yes
    Rate Limiting Yes
    Time based QoS Yes
    Queue Handling Yes
    Strict Priority Queue (SPQ) Yes
    Weighted Round Robin (WRR) Yes
    Weighted Deficit Round Robin (WDRR) Yes
    SPQ + WRR Yes
    Weighted Random Early Detection (WRED) Yes
    Simple Random Early Detection (SRED) Yes
    Port-based Bandwidth Control Yes
    Flow-based bandwidth Control Yes
    Queue-based Bandwidth Control Yes
    Max Access Control List (ACL) Entries Yes
    MAC Access List Yes
    IP Access List Yes
    IPv6 Access List Yes
    Time based ACL Yes
    CPU Interface Filtering Yes
    SSH Yes
    SSL Yes
    Port Security Yes
    Broadcast/Multicast/Unicast Storm Control Yes
    Traffic Segmentation Yes
    IP-MAC-Port Binding (IMPB) Yes
    DHCP Snooping Yes
    IP Source Guard Yes
    Dynamic ARP Inspection (DAI) Yes
    IPv6 Snooping Yes
    IPv6 Route Advertisement (RA) Guard Yes
    DHCPv6 Guard Yes
    D-Link Safeguard Engine Yes
    IPv6 ND Inspection Yes
    NetBIOS/NetBEUI filtering Yes
    L3 Control Packet Filtering Yes
    DHCP Server Screening Yes
    DHCP Client Filtering Yes
    ARP Spoofing Prevention Yes
    DoS Attack Prevention Yes
    BPDU Attack Protection Yes
    802.1X Yes
    Port based 802.1X Authentication Yes
    Host based 802.1X Authentication Yes
    Identity Driven 802.1X Policy Assignment Yes
    Web-based Access Control (WAC) Yes
    Port based WAC Authentication Yes
    Identity Driven WAC Policy Assignment Yes
    Host based WAC Authentication Yes
    MAC-based Access Control (MAC) Yes
    Host based MAC Authentication Yes
    Port based MAC Authentication Yes
    Identity Driven MAC Policy Assignment Yes
    Compound Authentication Yes
    Guest VLAN Yes
    Microsoft® NAP Support Yes
    Authentication for Management Access Yes
    Privilege Level for Management Access Yes
    RADIUS Yes
    RADIUS Accounting Yes
    TACACS+ Yes
    Authentication Database Failover Yes
    Trusted Host Yes
    Cable Diagnostics Yes
    802.3ah Ethernet Link OAM Yes
    D-link Unidirectional Link Detection (DULD) Yes
    Dying Gasp Yes
    802.1ag Connectivity Fault Management (CFM) Yes
    Y.1731 OAM Yes
    Optical Transceiver Digital Diagnostic Monitoring (DDM) Yes
    Network Time Protocol (NTP) Yes
    Simple Network Time Protocol (SNTP) Yes
    Web-based GUI Yes
    Telnet Server Yes
    Command Line Interface (CLI) Yes
    SNMP Yes
    Telnet Client Yes
    SNMP Trap Yes
    TFTP Client Yes
    Secured FTP (SFTP) Server Yes
    System Log Yes
    ZModem Yes
    Command Logging Yes
    SMTP Yes
    RMONv2 Yes
    RMONv1 Yes
    LLDP Yes
    LLDP-MED Yes
    DHCP/BootP Client Yes
    D-Link Discover Protocol (DDP) Yes
    DHCP relay Yes
    DHCP Auto-configuration Yes
    DHCP Server Yes
    PPPoE Circuit-ID Tag Insertion Yes
    Dual Images Yes
    Flash file system Yes
    Multiple Images Yes
    Dual Configurations Yes
    Multiple Configurations Yes
    Editable Login Banner Yes
    Editable System Prompt Yes
    Debug Command Yes
    DNS Client Yes
    Password Recovery Yes
    MTU Setting Yes
    Password Encryption Yes
    Ping Yes
    Traceroute Yes
    sFlow Yes
    Microsoft® Network Load Balancing (NLB) Yes
    10/100/1000BASE-T ports 24
    10GBASE-T ports 2
    10G SFP+ ports 4
    1000Base-T Interface 24
    1000Base-T PoE Interface 0
    1000M SFP Interface 0
    100M SFP Interface 0
    10G SFP+ Interface 4
    10GBase-T Interface 2
    Console Port 1
    RJ-45 Console port 1
    RJ-45 Management Port 1
    USB 2.0 port 1
    USB Port 1
