D Link ANT24-CB06N

Last Sold  1 sold in last 17 hours

Last updated: 03-10-2023

Item code: G1235GA

  • Operating Frequency Range
  • 2.4~2.5 GHz
  • 4.9~5.75 GHz



  •  Ask a Question

    D Link ANT24-CB06N

    Ask a Question

      Estimated Delivery: Jun 01 – Jun 03
      ... people are viewing this right now
    Compare
    Guaranteed Safe Checkout

    Description:

    D-Link, the industry pioneer in wireless networking, introduces the D-Link ANT24-CB03N, ANT24-CB06N, and ANT24-CB09N Antenna RF Cables. These products are designed for outdoor or rooftop installations when distance between a wireless Access Point (AP) and an antenna is required. With these Radio Frequency (RF) cables and D-Link’s ANT24 line of outdoor antennas, an indoor wireless AP/Bridge can be used in an outdoor deployment*.
    The D-Link ANT24 Antenna RF Cables are available in three lengths: 3m (9.84ft); 6m (19.68ft); and 9m (29.52ft). All of them can be inter-connected.  On one end of each cable is an “N-plug” and on the other end is an “N-jack” with high-quality N-type connectors.
    The D-Link Antenna RF Cables are based on the HDF-400 specification to minimize the signal loss introduced to a wireless LAN. The frequency responses of the cables coincide with the 2.4GHz ISM band so that the cables are ideal for both IEEE 802.11b and IEEE 802.11g WLANs. With 50 ohms of impedance, the RF cables can be used with most D-Link WLAN products. This impedance match eliminates any Voltage Standing Wave (VSW) issues in an RF circuit, and any noticeable decrease in the amplitude of the RF signal.
    D-Link includes a RF pigtail adapter in N-type *and SMA connectors with each of its ANT24 antennas. The D-Link Antenna Cables can be easily installed with surge protectors and D-Link Wireless APs. Using these reliable pre-cut RF cables with their pre-installed connectors ensures that the WLAN equipment operates optimally, providing the best performance possible. With a ANT24 Cable, deployment of an outdoor WLAN is now easier and more flexible than ever!

    General features:

    Operating Frequency Range
    • 2.4~2.5 GHz
    • 4.9~5.75 GHz
    Nominal Characteristic Impedance
    • 50Ω
    Insertion Loss  @ 2.4-2.5 GHz
    • 1.35~1.53dB
    Insertion Loss  @ 4.9-5.75 GHz
    • 2.22~2.41dB
    VSWR
    • 1.3:1 @2.4-2.5GHz
    • 1.6:1 @4.9-5.75GHz
    Cable Jacket
    • Black Polyethylene
    Connectors
    • N Plug & N Jack
    Minimum Bend Radius
    • 12.7mm
    Environment
    • Outdoor/ Indoor
    Operating Temperature Range
    • -40 C to +85 C
    Weatherproof
    • Yes

    Brand

    D-LINK
