SPECIFICATIONS:
|
| MODEL |
CS-CB8 (3MP) |
| CAMERA |
| IMAGE SENSOR |
1/2.8” 3-Megapixel . progressive-scan CMOS sensor |
| MINIMUM LIGHT INTENSITY |
0.01 Lux @ (F1.6, AGC ON), 0 Lux with infrared (data obtained from EZVIZ laboratories) |
| SHUTTER SPEED |
Self-adjusting shutter |
| LENS |
4 mm @ F1.6 Angle of view: 100° (Diagonal), 83° (Horizontal), 44° (Vertical) |
| ANGLE PT |
Rotation: 340°, Tilt: 65° |
| DAY & NIGHT |
Automatic switching infrared signal cut-off filter |
| DNR (DIGITAL NOISE REDUCTION) |
DNR 3D |
| NIGHT VISION |
Up to 49 ft / 15 m |
| VIDEO AND AUDIO |
| OPTIMAL RESOLUTION |
2304 × 1296 |
| ASPECT RATIO |
15 fps. Self-regulating during data transmission over the network |
| VIDEO COMPRESSION |
H.265/H.264 |
| VIDEO BITRATE |
Ultra-HD; HD; Standard. Self-adjusting bitrate. |
| AUDIO BITRATE |
Self-regulating |
| MAX BITRATE |
1.5 Mbps |
| NETWORK |
| WI-FI STANDARD |
IEEE802.11b, 802.11g, 802.11n |
| FREQUENCY RANGE |
2.4 GHz ~ 2.4835 GHz |
| BANDWIDTH OF THE CHANNEL |
Support 20MHz |
| SECURITY |
64 /128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| TRANSFER RATE |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
| WI-FI PAIRING |
Pairing AP |
| PROTOCOL |
Private EZVIZ Cloud Protocol |
| INTERFACE PROTOCOL |
Private EZVIZ Cloud Protocol |
| MINIMUM NETWORK REQUIREMENTS |
4 Mbps |
| FUNCTION |
| SMART ALARM |
Smart feature detects human movement |
| TWO-WAY CHAT |
Support |
| GENERAL FUNCTION |
Stabilization, Heart Rate, Password Protection, Video Encryption |
| STORAGE |
| INTERNAL MEMORY |
Micro SD card support (up to 256 GB) |
| CLOUD STORAGE |
Support EZVIZ CloudPlay storage service (Registration required) |
| GENERAL INFORMATION |
| OPERATING CONDITIONS |
-20° C to 50° C (-4° F to 122° F), 95% humidity or less (No condensation) |
| IP CLASS |
Weatherproof design |
| ELECTRICITY SUPPLY |
DC 5V / 2A |
| POWER CONSUMPTION |
10W . Max |
| BATTERY CAPACITY |
10400 mAh |
| PRODUCT DIMENSIONS |
183 x 116 x 166 mm (7.20 x 4.57 x 6.52 inches) |
| PACKING SIZE |
216 x 145 x 203 mm (8.50 x 5.71 x 7.99 inches) |
| WEIGHT |
net: 803 g (28.32 oz) With packaging: 1060 g (37.39 oz) |
| DETAILS OF PARTS |
| DETAILS OF PARTS |
– Camera CB8 2K |
| – Drill sample plate |
| – USB cable |
| – Screw set |
| – Quick installation guide |
| – Regulatory information |
| – Quick start Guide |
| CERTIFICATIONS |
| CERTIFICATIONS |
CE / FCC / WEEE / RoHS / REACH / UL |
