3 sold in last 15 hoursKey Features:
- Capacity: 960 GB
- Form Factor: 2.5″ 7mm
- Interface: SATA 6 Gb/s
- Sequential Read (128KB, QD32): 530 MB/s
- Sequential Write (128KB, QD32): 500 MB/s
- Random Read (4KB, QD32): 98,000 IOPS
- Random Write (4KB, QD32): 67,000 IOPS
- Terabytes Written (TBW)*: 2290 TB
- Drive Writes Per Day (DWPD): 1.3
- Mean Time Between Failures (MTBF): 1.5 million hours
- Uncorrectable Bit Error Rate (UBER): < 1 sector per 1017 bits read
- Supply Voltage: 5V (± 10%)
- Active Read (Typ.):2.9 W
- Active Write (Typ.): 4.6 W
- Idle: 1.5 W
- Operating Temperature: 0°C to 70°C (32°F to 158°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Synology SAT5200 Specifications
| SAT5200-480G | SAT5200-960G | SAT5200-1920G | ||
|---|---|---|---|---|
| General | Capacity | 480 GB | 960 GB | 1.92 TB |
| Form Factor | 2.5″ 7mm | 2.5″ 7mm | 2.5″ 7mm | |
| Interface | SATA 6 Gb/s | SATA 6 Gb/s | SATA 6 Gb/s | |
| Performance | Sequential Read (128KB, QD32) | 530 MB/s | 530 MB/s | 530 MB/s |
| Sequential Write (128KB, QD32) | 500 MB/s | 500 MB/s | 500 MB/s | |
| Random Read (4KB, QD32) | 95,000 IOPS | 98,000 IOPS | 98,000 IOPS | |
| Random Write (4KB, QD32) | 55,000 IOPS | 67,000 IOPS | 60,000 IOPS | |
| Endurance and Reliability | Terabytes Written (TBW)* | 1145 TB | 2290 TB | 4581 TB |
| Drive Writes Per Day (DWPD) | 1.3 | 1.3 | 1.3 | |
| Mean Time Between Failures (MTBF) | 1.5 million hours | 1.5 million hours | 1.5 million hours | |
| Uncorrectable Bit Error Rate (UBER) | < 1 sector per 1017Â bits read | < 1 sector per 1017Â bits read | < 1 sector per 1017Â bits read | |
| Power Loss Protection | ||||
| Warranty* | 5 Years | 5 Years | 5 Years | |
| Power Consumption | Supply Voltage | 5V (± 10%) | 5V (± 10%) | 5V (± 10%) |
| Active Read (Typ.) | 2.6 W | 2.9 W | 3.1 W | |
| Active Write (Typ.) | 4.2 W | 4.6 W | 5.1 W | |
| Idle | 1.4 W | 1.5 W | 1.6 W | |
| Temperature | Operating Temperature | 0°C to 70°C (32°F to 158°F) | 0°C to 70°C (32°F to 158°F) | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) | -40°C to 85°C (-40°F to 185°F) | -40°C to 85°C (-40°F to 185°F) | |
| Others | Size (Height x Width x Depth) | 7 mm x 69.85 mm x 100 mm | 7 mm x 69.85 mm x 100 mm | 7 mm x 69.85 mm x 100 mm |
| Certification |
|
|||
Discription:
Enterprise-grade SSD built for Synology systems
Synology SAT5200 SATA SSD offers stable I/O performance while reducing the latency of critical services and applications. It is built to handle mixed and intensive 24/7 workloads without compromising on endurance, providing a streamlined storage experience on Synology systems with minimal service disruptions.
Performance
Up to 67,000 4K random write IOPS1
Endurance
1.3 DWPD for 24/7 enterprise workloads2
Reliability
End-to-end data protection and power loss protection
Lifetime Analytics
Actionable insight for optimal performance and longevity
Stable high performance for demanding environments
Engineered for demanding environments such as online transaction processing (OLTP) databases and virtualization deployments, Synology SAT5200 delivers stable high performance at up to 67,000 4K random write IOPS, allowing firms to modernize existing storage infrastructure effortlessly.1
End-to-end data protection
Safeguards data integrity and consistency over the entire data transfer path.
Power loss protection circuit design
Dedicated capacitors provide sufficient power to flush data-in-flight into NAND flash during a power loss event, further preventing data corruption.
Purpose-built for Synology systems
Synology SAT5200 is thoroughly tested for compatibility with our systems following each engineering change, while firmware and component changes are strictly managed. Intensive I/O stress, power cycling, and temperature trials ensure that all products meet our strictest standards for quality and reliability.
 Synology SAT5200 Performance
Testbed
Our Enterprise SSD reviews leverage a Lenovo ThinkSystem SR850 for application tests (Note: we had to use an adapter card instead of a front bay slot due to a compatibility issue) and a Dell PowerEdge R740xd for synthetic benchmarks. The ThinkSystem SR850 is a well-equipped quad-CPU platform, offering CPU power well in excess of what’s needed to stress high-performance local storage. Synthetic tests that don’t require a lot of CPU resources use the more traditional dual-processor server. In both cases, the intent is to showcase local storage in the best light possible that aligns with storage vendor maximum drive specs.
Lenovo ThinkSystem SR850
- 4 x Intel Platinum 8160 CPU (2.1GHz x 24 Cores)
- 16 x 32GB DDR4-2666Mhz ECC DRAM
- 2 x RAID 930-8i 12Gb/s RAID Cards
- 8 NVMe Bays
- VMware ESXI 6.5
Dell PowerEdge R740xd
- 2 x Intel Gold 6130 CPU (2.1GHz x 16 Cores)
- 4 x 16GB DDR4-2666MHz ECC DRAM
- 1x PERC 730 2GB 12Gb/s RAID Card
- Add-in NVMe Adapter
- Ubuntu-16.04.3-desktop-amd64
