Raptor XR Designed for Phantom 3 Adv & Pro

Last Sold  3 sold in last 18 hours

Last updated: 08-06–2023

Item Code: G105600GA

  • Maximize performance
  • QuickAttach mounting system
  • Adjustable tilt of the range extender
  •  Ask a Question

    Raptor XR Designed for Phantom 3 Adv & Pro

    Ask a Question

      Estimated Delivery: Jun 19 – Jun 21
      ... people are viewing this right now
    Compare
    Guaranteed Safe Checkout

    Overview:

    DJI Phantom 3 Advanced drone is a predecessor to its newer model DJI Phantom 4. The basic kit allows for 30 minutes of uninterrupted flight, maximum speed of 65km/h.
    4Hawks antenna for DJI Phantom 3 Advanced & Pro models are operating in 2.4GHz with 14dBi gain and 5GHz also with 16dBi gain. Entire construction is 100% UV protected to assure longevity of the equipment. Additionally, part of the construction is made of aluminum to make the whole construction as light as possible. Mounting is made of stainless steel for rock solid stability.
    Mounting the range extender is easy and doesn’t require professional assistance. The entire set is lightweight and uniform (without any loose equipment pieces). Changing the direction of the antenna shouldn’t cause any difficulties, as the system was designed in a way that allows quick position change with just a single “click” to 5 different positions. This way you can be sure that you do not lose the connection with your drone.

    Specification

    electrical & mechanical parameters of Raptor renge extender.

    Electrical parameters

    Frequencies
    Port 1:   2.40 – 2.50 GHz
    Port 2:   2.40 – 2.50 GHz
    Gain
    Port 1:   14 dBi  (+/- 1 dBi)
    Port 2:   14 dBi  (+/- 1 dBi)
    VSWR
    Port 1:   < 1.20  (max. < 1.40)
    Port 2:   < 1.20  (max. < 1.40)
    Beamwidth
    Port 1:   35°/45°
    Port 2:   35°/45°
    Polarization
    Port 1:   Vertical
    Port 2:   Vertical
    Impedance
    Port 1:   50 Ω
    Port 2:   50 Ω

    Mechanical parameters

    Material
    Antenna:   Samsung ABS, polyurethane, aluminum, Stainless steel, Nylon, PTFE PCB
    Mounting:   Stainless steel + paint
    Weight
    ~ 540g (450g Antenna + 90g Mounting)
    Dimensions
    29.2 x 18.2 x 2.1 cm
    11.50 x 7.16 x 0.83 inch
    Connection
    Port 1:   RP-SMA female
    Port 2:   RP-SMA female
    Tilt adjustment
    5 tilt positions, OnClick system
    Mounting type
    On SMA connectors (Permanent)

    Brand

    DJI
