Raptor XR Designed for DJI Spark

Last Sold  1 sold in last 8 hours

Item Code: G105600 BK

Last updated: 30-10-2022


  • Maximize performance
  • Concurrent dual band 2.4 & 5GHz
  • No modification to the drone itself
  • Long range extension without external boosters
  • Design does not contain any removable parts
  • Complete solution
  •  Ask a Question

    Raptor XR Designed for DJI Spark

    Ask a Question

      Estimated Delivery: Mar 23 – Mar 25
      ... people are viewing this right now

    Guaranteed Safe Checkout

    Item Code: G105600 BK

    Last updated: 30-10-2022

    Designed for drone enthusiasts, DJI Spark is perfect for holiday trips. Its long range allows its user to reach places that were earlier completely inaccessible, such as deep forests, canyons, lakes etc. The built-in camera allows recording videos in 4k.
    4Hawks antenna for DJI Spark model is highly advanced, operating in both 2.4GHz as well as 5GHz frequencies The concept behind the look of the antenna was to make it look like it was a part of the drone by default. Entire construction is 100% UV protected to assure longevity of the equipment. Additionally, part of the construction is made of aluminum to make the whole construction as light as possible. Mounting is made of stainless steel for rock solid stability. Mounting the range extender leads to permanent changes with the remote controller. The entire set is lightweight and uniform (without any loose equipment pieces). Changing the direction of the antenna shouldn’t cause any difficulties, as the system was designed in a way that allows quick position change with just a single “click”. This way you can be sure that you do not lose the connection with your drone.


    electrical & mechanical parameters of Raptor renge extender.

    Electrical parameters

    Port 1:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Port 2:   2.40 – 2.50 GHz & 5.00 – 5.80 GHz
    Port 1:   11 dBi  (+/- 1 dBi) & 14 dBi  (+/- 1 dBi)
    Port 2:   11 dBi  (+/- 1 dBi) & 14 dBi  (+/- 1 dBi)
    Port 1:   < 1.50  (max. < 2.00)
    Port 2:   < 1.50  (max. < 2.00)
    Port 1:   70°/40° & 40°/25°
    Port 2:   70°/40° & 40°/25°
    Port 1:   Vertical
    Port 2:   Vertical
    Port 1:   50 Ω
    Port 2:   50 Ω

    Mechanical parameters

    Antenna:   Samsung ABS, polyurethane, aluminum, Stainless steel, Nylon, PTFE PCB
    Mounting:   Stainless steel + paint
    ~ 520g (450g Antenna + 70g Mounting)
    29.2 x 18.2 x 2.1 cm
    11.50 x 7.16 x 0.83 inch
    Port 1:   RP-SMA female
    Port 2:   RP-SMA female
    Tilt adjustment
    3 tilt positions, OnClick system
    Mounting type
    On SMA connectors (Permanent)
