General specifications:
UPS technology: On line Performance
Power (VA): 5000
Power (W): 4500
Phases: Single-phase/Single-phase
Format: Versatile rack/tower
Physical characteristics
Product length (mm): 645
Product height (mm): 88
Product width (mm): 438
Product depth (mm): 645
Packed gross weight (kg): 39.80
Electrical protection
Protection spectrum: Discharge, Overload, Overvoltage, Tel/data line
Tel./data protection
Connector type: RJ45
Input technical characteristics
Number of primary phases: 1
Type of connection: Outlets
Output technical characteristics
Connection type: Outlet
Voltage output type: AC
Wave form: Pure sine wave
Input connection
Number of 10A outlets: 6
Number of 16A outlets: 1
Output connection
External battery connector: Yes
Outlets type: IEC outlet
IEC type: C13 (10A)
Number of 16A battery backup outlets: 1
Number of 10A outlets: 6
Number of 16A outlets: 1
Number of terminals: 1
Number of programmable terminals: 4
Number of programmable outlets: 4
Regulation
Automatic Voltage Regulation (AVR): Yes
Efficiency
Eco Mode efficiency: 95% pour [110-115/120/127 VAC] ; 97% pour [208/220/230/240 VAC]
Boost and Buck mode efficiency: 93% for [110-115/120/127 VAC] ; 95% for [208/220/230/240 VAC]
Battery mode efficiency: 92% pour [208/220/230/240 VAC]
Battery
Number: 6
Type : voltage (V): 12
Type : amperage-hour (ah): 10
Charging voltage: 82,1 VDC ± 1%
Recharging time (minutes): 90% in 4 after complete discharge
Material: sealed lead
Display
Indicator: LCD
Bypass
Manual bypass: External in option
Parallel connection
Parallel Kit: Not available
Management and communication
Communication via software available: Yes
Compatible communication software: InfoPower
SNMP: Yes
Environment
Noise level: < 45 dB
Type: Indoor
Norms
CE: Yes
RoHS: Yes
