Convenience and power for quarter scale!
With the DLE-30, you get the economy of a gasoline engine in the size of a glow engine.
Electronic ignition provides the spark for fast starting. Timing automatically adjusts for peak power throughout the rpm range. And a made-for-flight design ensures the best power-to-weight ratio for performance.
A rear-mounted pumper carb ensures easier installs and smooth idling before you fly — and dependable fuel flow while you are flying.
|
|
Specifications:
Stock Number: DLEG0031
Displacement: 30.5 cc (1.861 cu in)
Bore: 1.42 in (36 mm)
Stroke: 1.18 in (30 mm)
Weight: 2.4 lb (1.10 kg)
RPM Range: 1,600-8,500
Output: 3.7 hp @ 8,500 rpm
Requires: unleaded gasoline, oil, ignition battery & propeller
Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & manual
Suggested Propellers: 18×8, 18×10, 19×8 & 20×8
Suggested Break-in Prop: 18×8
Technical Data:
Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPopack (Voltage regulator required with LiPo or LiFe use.)
Compression Ratio: 7.6:1
Gasoline/Oil Mix: 30:1
Replacement Spark Plug: DLEG3526
Weight Breakdown: Engine: 32.1 oz (910 g); Muffler: 2.1 oz (60 g); Ignition: 4.2 oz (120g)
Recommended Products:
HCAM6351 Hobbico HydriMax Ultra 6V 2000mAh NiMH Pack
XOAQ1808 Xoar PJA 18×8 Beech Propeller
Recommended Options:
FPWP2212 FlightPower FP25 7.4V 2100mAh LiPo Battery w/Star Plug
FPWM0290 FlightPower 5A Voltage Regulator (if LiPo or LiFe pack is used.)
HCAM6416 Hobbico LiFeSource 6.6V 1100mAh 10C LiFe Pack
XOAQ1810 Xoar PJA 18×10 Beechwood Propeller
XOAQ1908 Xoar PJA 19×8 Beechwood Propeller
XOAQ2008 Xoar PJA 20×8 Beechwood Propeller
DLEG0301 Propeller Drill Guide 30/35RA/40T
