| Model |
CS-DP2C |
| Opening dimensions |
16.5 to 50 mm (0.65 to 1.97 inch) |
| Door dimensions |
35 to 105 mm (1.38 to 4.13 inches) |
| Sensor |
1/3″ Progressive Scan CMOS |
| Lenses |
2.0 mm @ F2.2, visual angle (diagonal): 155° |
| Day/night changeover |
ICR infrared filter |
| IR distance |
Max. 5 years |
| Max. resolution |
1080p / 2MP |
| Video frame rate |
15 fps |
| Cache interface |
MicroSD card slot (max. 256 GB) |
| Audio input |
Built-in high sensitivity microphone |
| Audio output |
Built-in high-power speaker |
| Smart warning signal |
PIR motion detection |
| Protocols |
EZVIZ Cloud Proprietary Protocol |
| Wi-Fi standard |
IEEE802.11b, 802.11g, 802.11n |
| Frequency range |
2.4GHz ~ 2.4835GHz |
| Channel width |
Supports 20 MHz |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission speed |
11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Screen |
4.3-inch color screen |
| Color |
Silver |
| Operating conditions |
-10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
| Energy source |
DC 5V (±10%) |
| Energy consumption |
Max. 2.2W |
| Dimensions |
Screen and Base: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch) |
| Weight |
