| Model |
Salicru 698CA000003 Online Double Conversion Twin RT2 1500VA UPS |
| Technology |
Online Double Conversion (True Double Conversion) |
| Format |
Tower or Rack-mountable (1U) |
| INPUT |
|
| Rated Voltage |
208 V / 220 V / 230 V / 240 V |
| Voltage Range (100% load) |
176 V ÷ 294 V |
| Rated Frequency |
50 / 60 Hz (auto-detection) |
| Frequency Range |
±5 Hz |
| Auto Detection of Frequency |
Yes |
| Protection |
Fuse or resettable thermal protection |
| OUTPUT |
|
| Power Factor |
0.9 |
| Rated Voltage |
208 V / 220 V / 230 V / 240 V |
| Voltage Accuracy (Battery Mode) |
±1.5% |
| Power (VA/W) |
1500 VA / 1350 W |
| Total Harmonic Distortion (THDv) |
< 2% linear load, < 5% non-linear load |
| Waveform (Battery Mode) |
Pure Sine Wave |
| Frequency |
50 / 60 Hz (same as input) |
| Frequency Accuracy (Battery Mode) |
±0.1 Hz |
| Admissible Overloads in Battery Mode |
< 120% for 1 minute / < 150% for 10 seconds |
| Admissible Overloads in Line Mode |
< 120% for 5 minutes / < 150% for 10 seconds / >150% for 1 second |
| Socket Type |
IEC (C13/C19) |
| Number of Sockets |
8 (Including programmable sockets) |
| Programmable Sockets |
Yes, critical/non-critical load configuration |
| BATTERY |
|
| Battery Type |
Pb-Ca sealed, AGM, maintenance-free |
| Charge Type |
I/U (constant current/constant voltage) |
| Recharge Time |
4 hours to 90% |
| Battery Test |
Automatic at every start + weekly tests |
| CHARGER |
|
| Temperature Voltage Compensation |
Yes |
| COMMUNICATION |
|
| Ports |
RS-232 / USB-HID |
| Intelligent Slot |
Yes, for SNMP / potential-free contacts / MODBUS |
| Monitoring Software |
Compatible with Windows, Linux, Mac |
| INDICATIONS |
|
| Type |
LCD + Keypad |
| Display Values |
Voltage, power, input/output frequency, battery voltage, % battery charge, % load, mode, faults, discharge time, mute |
| Operating Modes |
Normal / Stabilization (AVR) / Battery / Fault |
| Alarm |
Battery mode, low battery, charger failure, overload, polarity errors |
| Audible Alarm |
Every 10s for battery operation. Every 2s for low battery, polarity. Every 1s for overcharge. Continuous for fault. |
| Failure Display |
LCD |
| OTHER FUNCTIONS |
|
| Cold Start |
Yes |
| Emergency Stop (EPO) |
Yes |
| ADSL/Fax/Modem Transient Protector |
Yes |
| Green Function |
Automatic shut-off in battery mode with load <5% |
| Smart Fan Speed |
Yes, adjusts based on load |
| Site Wiring Fault |
Yes, phase-neutral rotation and earth absence detection |
| GENERAL |
|
| Operating Temperature |
0ºC to +40ºC |
| Relative Humidity |
Up to 95%, non-condensing |
| Maximum Operating Altitude |
2400 meters above sea level (degradation up to 5000 m) |
| Acoustic Noise at 1 Meter |
< 45 dB |
| STANDARDS |
|
| Safety |
EN IEC 62040-1 |
| Electromagnetic Compatibility (EMC) |
EN IEC 62040-2 |
| Operation |
EN IEC 62040-3 |
| Corporate Certification |
ISO 9001, ISO 14001, ISO 45001 |
| DIMENSIONS |
|
| Depth (mm) |
411 mm |
| Width (mm) |
438 mm |
| Height (mm) |
86 mm |
| WEIGHT |
|
| Weight (kg) |
13.5 kg |
| Warranty |
3 years on electronics, 2 years on battery replacement. |
