Technical Specifications:
TECHNOLOGY
Line-interactive
FORMAT
Tower
INPUT
Rated voltage
220 V / 230 V / 240 V AC
Voltage range
Until 162 V ÷ 290 V
Stabiliser
AVR Buck / Boost
Rated frequency
50 / 60 Hz
Auto~detection of frequency
Yes
Protection
Thermal re-arm or fuse (depending on model)
OUTPUT
Rated voltage
220 V / 230 V / 240 V AC
Voltage accuracy (battery mode)
±10%
Power (VA)
1100
Waveform (battery mode)
Simulated sineware
Frequency
50 / 60 Hz ± 1 Hz (1)
Transfer time
2 / 6 ms
Socket type
IEC
BATTERY
Battery type
Enclosed batteries Pb-Ca without maintenance, sealed, design life 3-5 years
Recharge time
4-6 hours until 90% capacity
User replaceable battery
Yes
Back up time
Up to 20 minutes
Battery replacement alarm
Yes
COMMUNICATION
Ports
USB HID
Monitoring software
Compatible with Windows, Linux, Unix and Mac
Downloadable from
support.salicru.com
INDICATIONS
Type
LED
Operating modes
Normal / Stabilisation (AVR) / Battery
Mains present
Green LED
Alarm
Output battery mode, low battery (back up time), charger failure and overload
Audible
Every 10 s for battery operation. Every 1 s for low battery. Every 0.5 s for overcharge. Continuous for fault 2 s for battery replacement.
Failure
Red LED
OTHER FUNCTIONS
Cold start (start-up from batteries)
Yes
Automatic restart
Yes, after the end of back up time
GENERAL
Operating temperature
0º C ÷ + 40º C
Relative humidity
Utill 90%, without condensation
Maxium operating altitude
2,400 masl
Acoustic noise at 1 metre
< 40 dB
STANDARDS
Safety
EN IEC 62040-1
Electromagnetic compatibility (EMC)
EN IEC 62040-2
Operation
EN IEC 62040-3
Corporate cerification
ISO 9001, ISO 14001, ISO 45001
DIMENSIONS
Depth (mm)
320
Width (mm)
130
Height (mm)
182
WEIGHT
Weight (kg)
8.2
