Technical Specifications:
TECHNOLOGY
On-line double-conversion
FORMAT
Convertible tower/rack
INPUT
Voltage
220 / 230 / 240 V
Voltage range
110 ÷ 300 V up to 50% load
Rated frequency
50 / 60 Hz (auto-detection)
Frequency range
±4 Hz
Total harmonic distortion (THDi)
?4%
Power factor
>0,99 al 100% carga // 0,97 al 50% carga
OUTPUT
Power factor
1 (2)
Voltage
208 / 220 / 230 / 240 V
Static accuracy
±1%
Power (VA/W)
10000 / 10000
Total harmonic distortion (THDv) Linerar load
<1%
Total harmonic distortion (THDv) Non~linear load
<4%
Synchronised frequency
±4 Hz
Frequency accuracy (battery mode)
±0.1 Hz
Eco-mode performance
≥99%
Total performance in On-line mode
?93 ÷ 94%
Admissible overloads
< 110% for 10 min / < 130% for 1 min / > 130 % for 1 s
Socket type
Terminals + PDU
Parallel
Yes, up to 3 units(3)
STATIC BYPASS
Voltage (V)
208 / 220 / 230 / 240 V (1)
Frequency range
50/60 Hz ±4 Hz
BATTERY
Protection
Against power surges, undervoltages and alternating current components
Battery type
Not included, Pb-Ca sealed, AGM, maintenance-free
Charge type
I/U (constant current/constant voltage)
Recharge time
7 ÷ 9 hours to 90%
CHARGER
Temperature voltage compensation
Yes
COMMUNICATION
Ports
USB / RS-232 / relay
Intelligent slot
Smart slot for SNMP / potential-free contacts / MODBUS
Monitoring software
Yes, for Windows, Linux and Mac
OTHER FUNCTIONS
Cold start (start-up from batteries)
Yes
Emergency stop (EPO)
Yes
OPERATING MODES
Frequency converter (CVCF)
Yes(4)
GENERAL
Operating temperature
0º C ÷ +40º C
Relative humidity
Up to 95%, non-condensing
Maxium operating altitude
2,400 masl (power degradation up to 5,000 m)
Acoustic noise at 1 metre
< 60 dB
STANDARDS
Safety
EN-IEC 62040-1
Electromagnetic compatibility (EMC)
EN 62040-2(C3)
Operation
VFI-SS-11 (EN-62040-3)
Corporate cerification
ISO 9001, ISO 14001, ISO 45001
DIMENSIONS
Depth (mm)
630
Width (mm)
438
Height (mm)
88
WEIGHT
Weight (kg)
20
